Components |
18 x 4” drivers with treated cones |
2-way design |
yes |
Sensitivity 1 W @ 4 m in accordance with EN 54-24 |
87 dB SPL |
SPLmax 100 V @ 4 m in accordance with EN 54-24 |
108 dB SPL |
Transformer options, power handling in acc. with EN 54-24 100 V |
310 W |
Nominal directivity H x V (-6 dB, average @ 1-4 kHz) |
130° x 14° |
Beam angle (h x w) @ 500 Hz |
360° x 25° |
Beam angle (h x w) @ 1000 Hz |
190° x 15° |
Beam angle (h x w) @ 2000 Hz |
120° x 14° |
Beam angle (h x w) @ 4000 Hz
|
95° x 8° |
Loudspeaker features |
|
Housing |
weatherproof aluminium housing, powder coated, steel bracings
|
Mounting points |
10 x M6 screw threads |
Connectors |
terminal connectors capable of receiving up to 4 mm², two per pin, terminal cover with dual cable gland for up to 10 mm cable diameter |
Standard colours |
black (RAL 9005), powder-coated |
Dimensions (W x H x D) |
approx. 130 x 2200 x 120 mm |
Weight |
approx. 19,5 kg |
